SPEC CHART
Shimano Aorista
| Line-up | Year | Salt or Fresh | Weight（ｇ） | Gear Ratio | Retrieve（cm/crank） | Max Drag（kg） | Mono line cap. (lb-m) | Fluoro line cap. (lb-m) | Braided line cap. (lb-m) | Handle Arm（mm） | Spool diameter (mm) | Spool stroke (mm) | Bearing (Ball/Roller) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CI4 C3000 | 2010 | Saltwater OK | 240 | 5 | 74 | 2.5 | 10-180, 12-150, 16-100 | 10-160 | 20-400 | 50 | 46.5 | 14.5 | 7/1 |
| BB 2500 | 2013 | Saltwater OK | 270 | 5.2 | 74 | 2.5 | 8-170, 10-150, 12-120 | 8-140, 10-125, 12-100 | 20-320, 24-220, 30-160 | 50 | 45 | 14.5 | 3/1 |
| BB C3000HG | 2013 | Saltwater OK | 265 | 6.2 | 89 | 2.5 | 10-180, 12-150, 16-100 | 10-160, 12-130, 16-100 | 20-400, 30-270, 40-180 | 50 | 45.5 | 14.5 | 3/1 |
| BB 4000 | 2013 | Saltwater OK | 355 | 5.1 | 80 | 4 | 14-170, 16-150, 20-125 | 12-190, 16-145, 20-115 | 20-500, 30-320, 40-210 | 55 | 50 | 17 | 3/1 |
IN POUND-YARD NOTATION
| Line-up | Year | Salt or Fresh | Weight（oz) | Gear Ratio | Retrieve（in/crank） | Max Drag（lb） | Mono line cap. (lb-yd) | Fluoro line cap. (lb-yd) | Braided line cap. (lb-yd) | Handle Arm（in） | Spool diameter (in) | Spool stroke (in) | Bearing (Ball/Roller) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CI4 C3000 | 2010 | Saltwater OK | 8.6 | 5 | 29.1 | 5.6 | 10-200, 12-165, 16-110 | 10-180 | 20-440 | 1.97 | 1.83 | 0.57 | 7/1 |
| BB 2500 | 2013 | Saltwater OK | 9.6 | 5.2 | 29.1 | 5.6 | 8-190, 10-165, 12-130 | 8-155, 10-140, 12-110 | 20-350, 24-240, 30-180 | 1.97 | 1.77 | 0.57 | 3/1 |
| BB C3000HG | 2013 | Saltwater OK | 9.5 | 6.2 | 35 | 5.6 | 10-200, 12-165, 16-110 | 10-180, 12-145, 16-110 | 20-440, 30-300, 40-200 | 1.97 | 1.79 | 0.57 | 3/1 |
| BB 4000 | 2013 | Saltwater OK | 12.7 | 5.1 | 31.5 | 8.9 | 14-190, 16-165, 20-140 | 12-210, 16-160, 20-130 | 20-550, 30-350, 40-230 | 2.17 | 1.97 | 0.67 | 3/1 |
