SPEC CHART
Shimano 2018 barchetta sc
Line-up | Year | Salt or Fresh | Weight(g) | Gear ratio | Retrieve(cm/crank) | Max drag (kg) | Mono line cap. (lb-m) | Braided line cap.(lbーm) | Handle Arm(mm) | Spool diameter (mm) | Spool width (mm) | Bearing (Ball/Roller) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
800 RIGHT | 2018 | Saltwater OK | 390 | 5.1 | 67 | 5 | 12-360, 16-250, 20-200 | 55-250, 60-200, 80-150 | 60/79 | 42 | 33 | 3/1 |
1000 RIGHT | 2018 | Saltwater OK | 380 | 5.1 | 67 | 5 | 16-330, 20-260, 22-210 | 55-300, 60-250, 80-200, 90-150 | 60/79 | 42 | 33 | 3/1 |
2000 RIGHT | 2018 | Saltwater OK | 395 | 5.1 | 67 | 5.5 | 20-300, 22-250, 25-210 | 60-300, 80-250, 90-200 | 60/79 | 42 | 38 | 3/1 |
3000 RIGHT | 2018 | Saltwater OK | 455 | 4.6 | 72 | 8 | 22-400, 25-350, 28-290 | 80-370, 90-300, 100-200 | 60/79 | 50 | 43 | 3/1 |
IN POUND-YARD NOTATION
Line-up | Year | Salt or Fresh | Weight(oz) | Gear ratio | Retrieve(in/crank) | Max drag (lb) | Mono line cap. (lb-yd) | Braided line cap.(lbーyd) | Handle Arm(in) | Spool diameter (in) | Spool width (in) | Bearing (Ball/Roller) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
800 RIGHT | 2018 | Saltwater OK | 13.9 | 5.1 | 26.4 | 11.1 | 12-400, 16-275, 20-220 | 55-275, 60-220, 80-165 | 2.36/3.11 | 1.65 | 1.3 | 3/1 |
1000 RIGHT | 2018 | Saltwater OK | 13.6 | 5.1 | 26.4 | 11.1 | 16-365, 20-290, 22-230 | 55-330, 60-275, 80-220, 90-165 | 2.36/3.11 | 1.65 | 1.3 | 3/1 |
2000 RIGHT | 2018 | Saltwater OK | 14.1 | 5.1 | 26.4 | 12.2 | 20-330, 22-275, 25-230 | 60-330, 80-275, 90-220 | 2.36/3.11 | 1.65 | 1.5 | 3/1 |
3000 RIGHT | 2018 | Saltwater OK | 16.3 | 4.6 | 28.3 | 17.8 | 22-440, 25-385, 28-320 | 80-410, 90-330, 100-220 | 2.36/3.11 | 1.97 | 1.69 | 3/1 |
