Technology Features of Shimano 2018 OCEA CONQUEST CT 201PG LEFT
HAGANE
“HAGANE” is more than just a material name; it’s a design philosophy centered around creating reels that offer unmatched longevity and smoothness. The term "HAGANE" itself, which means "steel" in Japanese, symbolizes strength and resilience. However, in Shimano's context, it transcends traditional interpretations, representing a suite of advanced technologies aimed at enhancing performance and durability. In other words, when they say "HAGANE", they do not actually mean that HAGANE(= steel) is used. “HAGANE” promises robustness that can be used with peace of mind even in the harshest of conditions, an unchanging, exquisite winding feel, and winding power that exceeds the imagination."HAGANE Gear" or "HAGANE Body" is Shimano's engineering concept and philosophy.
MICRO MODULE GEAR
The gear teeth surfaces in the MICRO MODULE GEAR are finer and mesh more closely together than traditional gears, resulting in minimal power loss and a smooth, powerful winding experience. Additionally, the increased number of meshing teeth provides greater strength compared to conventional gears. This unique Shimano gear system achieves a balance of smoothness and durability.
X-SHIP
X-SHIP features an enlarged drive gear, optimal positioning of the pinion and drive gears, and two-point support for the pinion gear with bearings. This robust gear engagement maintains smooth and efficient reeling even under heavy loads.
FALLEVER
FALLEVER is a newly designed lever that allows for easy and precise control of fall speed, which was previously difficult to manage. By moving the lever forward or backward, you can adjust the mechanical brake to either increase or decrease the fall speed. This enables more strategic fishing, such as allowing the lure to fall quickly in mid-water and slowly near the bottom. Additionally, during casting, the brake can be applied to prevent backlash, and then smoothly released for a free fall. FALLEVER also allows for seamless operation of casting and subsequent actions with a single lever.
S COMPACT BODY
The S COMPACT BODY design reduces the diameter of the reel on the palming side compared to the handle side, creating a more comfortable grip that feels as if the reel is one size smaller. This enhances palming comfort and control.
EXCITING DRAG SOUND
EXCITING DRAG SOUND is a feature that produces a sound when the line is pulled out from the spool by a fish. Unlike traditional baitcasting reels, which typically do not emit a drag sound, this feature enhances the angler's experience by stimulating their senses, making the fight with the fish even more enjoyable.
SA-RB
A-RB bearings feature a special anti-corrosion treatment that significantly improves their rust resistance. The SA-RB takes this further by sealing the sides with anti-corrosion materials, greatly reducing salt crystallization and salt damage inside the bearing.
LED BACK LIGHT
The LED BACK LIGHT allows for easy viewing of the reel's LCD screen even at night. You can choose different lighting modes, such as lighting up only when the spool is rotating, lighting up for 5 seconds when a button is pressed, or staying on continuously. This feature is particularly useful for night fishing when it's important to accurately monitor the depth on the LCD screen counter.
Shimano 2018 ocea conquest CT Spec Chart
Shimano 2018 ocea conquest CT Line-up
| Line-up | Year | Salt or Fresh | Weight（ｇ） | Gear ratio | Retrieve（cm/crank） | Max drag (kg) | Mono line cap. (lb-m) | Braided line cap.（lbｰm） | Handle Arm（mm） | Spool diameter (mm) | Spool width (mm) | Bearing (Ball/Roller) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 200HG RIGHT | 2018 | Saltwater OK | 340 | 6.2 | 78 | 5 | For braided line only | 20-440, 40-200 | 60 | 40 | 18 | 10/1 |
| 201HG LEFT | 2018 | Saltwater OK | 340 | 6.2 | 78 | 5 | For braided line only | 20-440, 40-200 | 60 | 40 | 18 | 10/1 |
| 200PG RIGHT | 2018 | Saltwater OK | 330 | 4.8 | 60 | 6 | For braided line only | 20-440, 40-200 | 48 | 40 | 18 | 12/1 |
| 201PG LEFT | 2018 | Saltwater OK | 330 | 4.8 | 60 | 6 | For braided line only | 20-440, 40-200 | 48 | 40 | 18 | 12/1 |
Specifications in Pound-Yard Notation
| Line-up | Year | Salt or Fresh | Weight（oz） | Gear ratio | Retrieve（in/crank） | Max drag (lb) | Mono line cap. (lb-yd) | Braided line cap.（lbｰyd） | Handle Arm（in） | Spool diameter (in) | Spool width (in) | Bearing (Ball/Roller) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 200HG RIGHT | 2018 | Saltwater OK | 12.1 | 6.2 | 30.7 | 11.1 | For braided line only | 20-485, 40-220 | 2.36 | 1.57 | 0.71 | 10/1 |
| 201HG LEFT | 2018 | Saltwater OK | 12.1 | 6.2 | 30.7 | 11.1 | For braided line only | 20-485, 40-220 | 2.36 | 1.57 | 0.71 | 10/1 |
| 200PG RIGHT | 2018 | Saltwater OK | 11.8 | 4.8 | 23.6 | 13.3 | For braided line only | 20-485, 40-220 | 1.89 | 1.57 | 0.71 | 12/1 |
| 201PG LEFT | 2018 | Saltwater OK | 11.8 | 4.8 | 23.6 | 13.3 | For braided line only | 20-485, 40-220 | 1.89 | 1.57 | 0.71 | 12/1 |
