Tableau des spécifications Shimano 2022 grappler bb
| Gamme | Année | Eau salée ou douce | Poids（g） | Rapport de transmission | Récupération（cm/tour de manivelle） | Frein max (kg) | Capacité ligne mono. (lb-m) | Capacité tresse（lbｰm） | Manivelle（mm） | Diamètre de la bobine (mm) | Largeur de la bobine (mm) | Roulements (Bille/Galet) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 150HG DROITE | 2022 | Compatible eau salée | 210 | 7.2 | 72 | 5 | Uniquement pour tresse | 16-400, 20-330, 30-200 | 60 | 32 | 22 | 4/1 |
| 151HG GAUCHE | 2022 | Compatible eau salée | 210 | 7.2 | 72 | 5 | Uniquement pour tresse | 16-400, 20-330, 30-200 | 60 | 32 | 22 | 4/1 |
Spécifications en livres-yards
| Gamme | Année | Eau salée ou douce | Poids（oz） | Rapport de transmission | Récupération（po/tour de manivelle） | Frein max (lb) | Capacité ligne mono. (lb-yd) | Capacité tresse（lbｰyd） | Manivelle（po） | Diamètre de la bobine (po) | Largeur de la bobine (po) | Roulements (Bille/Galet) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 150HG DROITE | 2022 | Compatible eau salée | 7.5 | 7.2 | 28.3 | 11.1 | Uniquement pour tresse | 16-440, 20-365, 30-220 | 2.36 | 1.26 | 0.87 | 4/1 |
| 151HG GAUCHE | 2022 | Compatible eau salée | 7.5 | 7.2 | 28.3 | 11.1 | Uniquement pour tresse | 16-440, 20-365, 30-220 | 2.36 | 1.26 | 0.87 | 4/1 |
Fonctionnalités technologiques de Shimano 2022 GRAPPLER BB
HAGANE
“HAGANE” is more than just a material name; it’s a design philosophy centered around creating reels that offer unmatched longevity and smoothness. The term "HAGANE" itself, which means "steel" in Japanese, symbolizes strength and resilience. However, in Shimano's context, it transcends traditional interpretations, representing a suite of advanced technologies aimed at enhancing performance and durability. In other words, when they say "HAGANE", they do not actually mean that HAGANE(= steel) is used. “HAGANE” promises robustness that can be used with peace of mind even in the harshest of conditions, an unchanging, exquisite winding feel, and winding power that exceeds the imagination."HAGANE Gear" or "HAGANE Body" is Shimano's engineering concept and philosophy.
X-PROTECT
X-PROTECT provides robust protection against water ingress into the reel by combining a labyrinth-structured waterproof wall with special water-repellent grease. In small to medium-sized spinning reels, which require lighter rotation, a non-contact structure is emphasized to maintain rotational lightness. This high waterproof performance is achieved by combining traditional water-repellent treatments with a labyrinth structure that prevents water penetration without direct contact. This technology is applied to areas such as the stopper bearing and line roller.
For larger spinning reels that require higher waterproof performance, a contact-type waterproof structure is used. Low-friction seal materials physically block seawater entry paths, achieving high waterproof performance while minimizing rotational resistance. This contact-type waterproofing is applied to the stopper bearing and line roller, with the stopper bearing achieving an IPX8 waterproof rating.
For larger spinning reels that require higher waterproof performance, a contact-type waterproof structure is used. Low-friction seal materials physically block seawater entry paths, achieving high waterproof performance while minimizing rotational resistance. This contact-type waterproofing is applied to the stopper bearing and line roller, with the stopper bearing achieving an IPX8 waterproof rating.
SA-RB
A-RB bearings feature a special anti-corrosion treatment that significantly improves their rust resistance. The SA-RB takes this further by sealing the sides with anti-corrosion materials, greatly reducing salt crystallization and salt damage inside the bearing.
